QUINT-PS/ 3AC/24DC/10

3

Ordering data

Description

Primary-switched power supply with SFB technology, 3 AC, output current

Type

QUINT-PS/ 3AC/24DC/10

Order No.

2866705

Pcs. / Pkt.

1

10 A

Accessories

Assembly adapter for QUINT POWER 10A on S7-300 rail

Universal wall adapter

Fan for QUINT-PS ... power supply. The fan eliminates the position-

Type

QUINT-PS-ADAPTERS7/2

UWA 182/52

QUINT-PS/FAN/4

Order No.

2938206

2938235

2320076

Pcs. / Pkt.

1

1

1

dependent derating of the power supply.

4

Technical data

Input data

Input nominal voltage range

AC input voltage range

DC input voltage range

AC frequency range

DC frequency range

Current consumption

Inrush current limitation

I 2 t

Power failure bypass

Typical response time

Protective circuitry

Recommended backup fuse for mains protection

Discharge current to PE

Output data

Nominal output voltage

Setting range of the output voltage

Output current

Magnetic fuse tripping

Derating

Power loss nominal load max.

Maximum power dissipation idling

Efficiency

Ascent time

Residual ripple

Peak switching voltages

Connection in parallel

Connection in series

Surge protection against internal surge voltages

Resistance to reverse feed

3x 400 V AC ... 500 V AC

3x 320 V AC ... 575 V AC

2x 360 V AC ... 575 V AC

450 V DC ... 800 V DC

45 Hz ... 65 Hz

0 Hz

Approx. 3x 1.2 A (400 V AC)

Approx. 3x 1 A (500 V AC)

< 15 A (typical)

< 1.5 A 2 s

> 20 ms (400 V AC)

> 30 ms (500 V AC)

<1s

Transient surge protection Varistor, gas-filled surge arrester

6 A (characteristic B)

10 A (characteristic B)

16 A (characteristic B)

< 3.5 mA

24 V DC ±1%

18 V DC ... 29.5 V DC (> 24 V constant capacity)

10 A (-25°C ... 70°C, U OUT = 24 V DC)

15 A (with POWER BOOST, -25°C ... 40°C permanently, U OUT = 24 V DC)

60 A (with SFB technology, 12 ms)

max 6 A (characteristic B)

max 4 A (Characteristic C)

From +60°C 2.5% per Kelvin

19 W

7W

> 93 % (at 400 V AC and nominal values)

< 1 s (U OUT (10% ... 90%))

< 20 mV PP (with nominal values)

< 20 mV PP (at nominal values, 20 MHz)

Yes, for redundancy and increased capacity

Yes

Yes, limited to approx. 35 V DC

max. 35 V DC

103131_en_01

PHOENIX CONTACT

3
